Function
SHR APPLICATION
Permanent hair removal
Skin rejuvenation
Pigment removal
Vascular treatment
Acne therapy
LASER APPLICATION
Pigmentation
Dispel the Spots
Decrease Vascular
Skin care
Shrink Pores
Tattoo Removal
Birthmark Removal
Eyeline Removal
Balance Oil
Mole Removal
RF APPLICATION
Cheek, jaw, neck skin tightening
Nasolabial fold improvement
Waist and abdomen, limbs, weight loss
Hips, big legs, orange peel-like skin improvement
Working principle
SHR
SHR stands for Super Hair Removal, a technology of permanent hair removal. The system combines lasertechnology and the benefits of the pulsating light method achieving practically painless results. Even hairswhich until now have been difficult or even impossible to be removed can now be treated. The treatment ismore pleasant than with the conventional systems and your skin is better protected.
Q-SWITCHED ND YAG LASER
The special wavelength of YAG laser can penetrate skin of human body according to the principle of "selectivelaser decomposing", the instrument uses the laser-wave to break Chromophore into pieces, and to achievethe purpose of de-freckle with these pieces naturally absorbed by the body. With Carbon assisted laser tips,can do laser toning, rejuvenation, whitening and etc skin beauty treatment.
FRACTIONAL RF
Fractional RF delivers accurate Bipolar RF energy to the skin by a tip built of an array of small pins andreturn electrodes to create microscopic thermal zones (MTZ). The RF energy introduce fractional thermalinto the deep dermis and create potential healing effects in the microscopic thermal zones. Undamagedtissue between the electrode pins acted as a healing server to accelerate the collagen rebuilding and skintissues remodeling. Unlike the traditional laser therapy, the majority of the fractional RF energy is focusedin the dermis while only a small percentage of the surface is effected, resulting in deep volumetric dermalheating and ultimate result.
Advantage
1. 3000W stable power
2. SHR,Q-switched nd yag laser, fractional RF widely used advanced technology combine in one system
3. Sapphire crystal IPL handpiece with 5 filters, wavelength ended at 950nm
4. Laser handpiece with 3 tips: 532nm, 1064nm, carbon assisted laser tip
5. Fractional RF handpiece with 2 spot sizes, no consumable, durable tip life span
6. 10.6 inch touch screen-universal rotating
7. Super strong energy, stable, integrated and independent construction, easy maintenance.
8. Auto checking water flow&water temperature, ensure system working safe.
10. Strong cooling, very comfortable treatment
11. Laser aim beam
Speficiation
| SHR |
| Filters |
430/480/530/580/640/690/750nm |
| Spot size |
15mm*50mm or 8mm*40mm |
| Lamp longevity |
200,000shots |
| Energy |
10-50J |
| Pulse repetition rate |
1-5Hz |
| Pulse Width |
1.0-5ms |
| Skin cooling |
-4°c-10°c |
| Power |
2000W |
| Capacitors |
44,000uf |
| FRACTIONAL RF |
| Treatment head |
23*23mm 64pin
43*43mm 196pin |
| Output Frequency |
6.78MHz |
| Energy |
Max 142mj/pin |
| Treatment Mode |
continuous/pulse |
| Power |
120W |
| Q-SWITCHED ND YAG LASER |
| Treatment head |
1064&532&soft laser treatment tips |
| Energy |
100-1200mj |
| Guiding light |
635nm |
| Pulse duration |
8ns |
| Frequency |
1-6Hz |
| Power |
600W |
| System |
| Display |
10.4” inch true color touch screen |
| Voltage |
220-240V/50Hz,100-110V/60Hz |
| Machine Power |
3000W |
| Cooling system |
Wind+water+semiconductor |
| Machine Dimensions |
50cm*55cm*115cm |
| Package Dimensions |
58cm*60cm*130cm |
| Net weight |
45kg |
| Total weight |
60kg |
